ROBOT L3
ROBOT LMR LF5
ROBOT LMR LF5
application
Logistics
Car
Medicine
3C Electronic
Food
Photovoltaic
|
InsideAllow |
index |
parameter |
|
Basic parameters |
rated load |
1000Kg |
|
external dimensions |
1250（L）×1200（W）×190（H） |
|
|
self-weight |
300kg |
|
|
navigation method |
qr code /VSLAM/LSLAM |
|
|
rotating diameter |
1640mm |
|
|
Maximum height fork lift |
330mm |
|
|
The height of the fork is lowered |
90mm |
|
|
Single fork width |
164mm |
|
|
Forks with width |
600mm |
|
|
Fork width inside |
272mm |
|
|
The fork extends out of the car bodymax |
≤1400 |
|
|
Minimum ground clearance |
25mm |
|
|
Adaptable pallet fork hole height |
100-130mm |
|
|
Applicable to pallet fork hole outer width |
≥700mm |
|
|
Suitable fork hole inner width of tray |
≤180mm |
|
|
Applicable tray size |
（1000~1300）*（1000~1300）mm |
|
|
Obstacle avoidance laser scanning surface height |
145mm |
|
|
Pallet recognition laser scanning surface height |
145mm |
|
|
Display |
5inch |
|
|
safety protection |
laser barrier avoidance |
One diagonally diagonally in front and back |
|
anti-collision bar detection |
have |
|
|
emergency stop button |
One left and right |
|
|
sound and light alarm |
have |
|
|
Check whether the tray exists or not |
have |
|
|
Fork tip collision detection |
have |
|
|
motion performance |
How to exercise |
Double wheel differential, support forward/Retreat, turn in a radian, rotate in place |
|
Running speed (no load/Full load) |
1.8/1.5m/s |
|
|
Positioning accuracy |
±10mm |
|
|
Angle accuracy |
±1 |
|
|
Maximum climbing capability (no loading/Full load) |
4° |
|
|
Single pick-up and delivery time (s） |
±28 |
|
|
carry/Fork drop time (no load /Full load) |
≤8.5 |
|
|
carry/Return time (no load /Full load) |
≤4.5 |
|
|
battery-related |
rated voltage |
48V |
|
capacity |
28 Ah |
|
|
number of charge cycles |
Complete charge and discharge1500Second-rate |
|
|
rated operating time |
≥8H |
|
|
charging time |
≤1.5H |
|
|
automatic battery swap function |
/ |
|
|
battery type |
lithium iron phosphate |
